Broadcom HEDS-5540-A06 Sensor Transducer

Description

Broadcom HEDS-5540-A06 Sensor Transducer SUPPLIER IN BANGLADESH PRICE IN BANGLADESH IMPORTER IN BANGLADESH BD

The Broadcom HEDS-5540-A06 is an optical incremental encoder used for motion sensing and position tracking applications. This encoder provides accurate rotational feedback, making it ideal for applications where precise positioning is essential.

Key Parameters

1. Resolution:
   • 500 CPR (Counts per Revolution)
   • Provides high resolution for detailed motion control.
2. Output:
   • Quadrature Output: Produces two digital signals in quadrature (A and B) that represent the position and direction of rotation.
   • Square Wave: Standard output type for compatibility with controllers and drives.
3. Shaft Diameter:
   • Designed to fit a 6mm shaft, ensuring compatibility with most small motors.
4. Operating Voltage:
   • Typical operating voltage of 5V, suitable for low-power systems.
5. Signal Type:
   • Digital (TTL-compatible), enabling easy integration with digital systems.
6. Operating Temperature Range:
   • -40°C to +100°C, allowing it to function in a wide range of environments.
7. Mounting:
   • Often configured with a flexible mounting system to allow for quick and stable attachment to motor shafts.

Applications

• Robotics: Used for precise position control and feedback in robotic joints or wheels.
• Industrial Automation: Commonly deployed in automated machinery for precise motion control and feedback.
• CNC Machines: Provides accurate position feedback for tool positioning.
• Motor Control: Suitable for applications requiring speed and direction feedback in servo motors.
• Medical Devices: Utilized in devices that need precise motion control, such as imaging systems and infusion pumps.
