Schneider TM5SE2IC01024 Incremental Encoder Inputs

TM5SE2IC01024

TM5ACBM15

TM5PCRS4

TM5SDI6D

TM5C24D12R

TM2DDI16DK

TM5C12D6T6L

TM3DQ8TG

TM5SAI2H





We are not an Authorized dealer or distributor of this brand; we just import it from abroad and sell it bd the local market

Schneider TM5SE2IC01024 Incremental Encoder Inputs Supplier In Bangladesh, Importer In Bangladesh, Best Price In Bangladesh BD





Key Features

• Input Channels: 2 channels for incremental encoders

• Encoder Type: Incremental

• Input Frequency: 100 kHz per channel

• Encoder Supply: 24 V DC

• Encoder Input: 24 V DC asymmetrical

• Additional Inputs: 2 auxiliary 24 V DC inputs

• Input Resolution: 16 or 32 bits

• Cycle Time: ≤ 2 ms

• Isolation: 500 Vrms AC between channel and bus

• Discrete Input Logic: Sink

• Discrete Input Voltage: 24 V DC

• Discrete Input Current: 1.3 mA at 24 V

• Input Resistance: 18.4 kΩ

• Current Consumption: 2 mA from 5 V DC bus; 63 mA from 24 V DC input/output

• Power Dissipation: ≤ 1.51 W

• Weight: 0.025 kg

• Protection Class: IP20 (IEC 61131-2)

• Pollution Degree: 2 (IEC 60664)

• Operating Temperature: 0…50 °C (vertical installation); 0…55 °C (horizontal installation without derating); 0…60 °C (horizontal installation with derating)

• Storage Temperature: -25…70 °C

• Relative Humidity: 5…95 % without condensation

• Altitude: 0…2000 m operating; 0…3000 m storage

---

🛠️ Applications

• Industrial Automation: Monitoring and controlling position in automated systems

• Material Handling: Feedback in conveyors and robotic arms

• Packaging Machinery: Ensuring accurate positioning in packaging lines

• Machine Tools: Position feedback for CNC machines
