Telemecanique XMLG025D21 Pressure Sensor

We are not an Authorized dealer or distributor of this brand; we just import it from abroad and sell it bd the local market

Telemecanique XMLG025D21 Pressure Sensor Supplier In Bangladesh, Importer In Bangladesh, Best Price In Bangladesh BD





Key Features

• Pressure Range: 0 to 25 bar

• Output Type: Analog (4–20 mA, 2-wire)

• Electrical Connection: M12, 3-pin male connector

• Supply Voltage: 12–24 V DC (8–33 V DC operational)

• Accuracy: ±0.3% of the measuring range

• Repeatability: ±0.1% of the measuring range

• Response Time: < 2 ms

• Protection Class: IP66 and IP67

• Operating Temperature Range: -15°C to +85°C

• Materials in Contact with Fluid: Ceramic, FPM (Viton), Stainless Steel (AISI 303)

• Mechanical Durability: 10 million cycles

• Mounting Type: Threaded G 1/4 A (male) conforming to DIN 3852-E

---

🛠️ Applications

• Industrial Automation: Monitoring and controlling pressure in automated systems.

• Hydraulic Systems: Pressure measurement in hydraulic circuits.

• Pneumatic Systems: Ensuring optimal pressure levels in pneumatic applications.

• Water Treatment: Monitoring pressure in water filtration and distribution systems.
