Temposonics RPM0200MR081A01 Position Sensor

We are not an Authorized dealer or distributor of this brand; we just import it from abroad and sell it bd the local market

Temposonics RPM0200MR081A01 Position Sensor Supplier In Bangladesh, Importer In Bangladesh, Best Price In Bangladesh BD





Key Features:

• Measurement Range: 200 mm stroke length

• Sensing Technology: Magnetostrictive, non-contact, absolute position measurement

• Output Interface: Synchronous Serial Interface (SSI)

• Resolution: Up to 1 µm

• Linearity: ±0.01% of full scale (minimum ±50 µm)

• Repeatability: Better than ±0.001% of full scale (minimum ±2.5 µm)

• Update Rate: Up to 4 kHz

• Operating Voltage: 24 V DC nominal (range: 20.4 to 28.8 V DC)

• Operating Temperature: -40°C to +85°C

• Protection Class: IP67 (sensor rod and electronics housing)

• Housing Material: Stainless steel for sensor rod; aluminum for electronics housing

• Mounting Options: Threaded flange or retaining ring for in-cylinder applications

• Magnet Compatibility: Ring magnet or slide magnet

---

Applications:

• Industrial Automation: Precise position measurement in automated machinery and equipment.

• Hydraulic and Pneumatic Cylinders: Integration into cylinders for accurate stroke measurement.

• Material Handling: Position feedback in conveyors, lifts, and robotic arms.

• Metalworking and Machine Tools: Monitoring and controlling tool positions and movements.

• Packaging Machinery: Ensuring accurate positioning in packaging processes.​
